URL

Overview

The URL source type fetches data from a web address. Use it for API endpoints, hosted CSV/JSON files, or any data feed accessible via HTTP/HTTPS.

Configuration

Required Fields

Field	Description
`url`	The full URL to the data source (API endpoint or hosted file URL).

HTTP Options

These fields are nested under the options object.

Field	Description
`method`	The HTTP method to use: `GET` (default), `POST`, `PUT`, or `PATCH`.
`headers`	Custom HTTP headers to include in the request (key-value pairs). Useful for API keys or custom tokens.
`query`	URL query parameters to append to the request (key-value pairs).
`body`	The request body (for `POST`, `PUT`, `PATCH` methods).
`timeout`	Request timeout in milliseconds.
`oauth`	DatasourceAuth ID for OAuth-protected APIs.

Authentication

No Authentication
Custom Headers
OAuth

For publicly accessible URLs, no additional configuration is needed.

For API key or token-based authentication, add the appropriate header in the headers configuration:

Header	Example
`Authorization`	`Bearer <your-token>`
`X-API-Key`	`<your-api-key>`

Supported File Formats

The URL source automatically detects the response format. The following formats are supported:

Format	Description
CSV	Comma-separated values. Delimiter is auto-detected (comma, semicolon, tab, pipe). See CSV Format Options for header-less file support.
JSON	Standard JSON files with a root array or object.
NDJSON	Newline-delimited JSON (one JSON object per line).
XML	XML files — the root element path is auto-detected.
Parquet	Apache Parquet columnar format.
Avro	Apache Avro serialization format.
XLSX	Microsoft Excel files.

Compressed responses (.gz, .zip) are automatically decompressed before parsing.

PGP Decryption

The URL source supports fetching PGP-encrypted files. When pgpPrivateKey is configured, the response is decrypted before decompression and parsing.

Field	Required	Description
`pgpPrivateKey`	Yes	The PGP/GPG private key in armored (ASCII) format.
`pgpPassphrase`	No	The passphrase for the private key, if encrypted.

Both armored (.asc) and binary (.pgp, .gpg) encrypted files are supported.

See the PGP Decryption guide for details on key generation, supported formats, and error handling.

Pagination

For APIs that paginate their responses, the URL source supports several pagination strategies:

Increment a query parameter (page number or offset) on each request.

Field	Description
`value`	The query parameter name (e.g. `page`, `offset`).
`startAt`	The initial value (default: `1`). Some APIs start at `0`.
`subtype`	`page` (page number) or `offset` (record offset).

Follow a URL found in the response body (e.g. a next attribute in the JSON response).

Field	Description
`value`	The JSON path to the next page URL in the response (e.g. `next_page_url`).

Use a token from the response body to request the next page.

Field	Description
`value`	The JSON path to the token in the response body.
`param`	The query parameter to use for the token in subsequent requests.
`removeParams`	Remove other URL parameters when paginating (optional).

Follow pagination URLs from the standard HTTP Link header (as defined by RFC 8288).

Use a value from the last entry of the current page to request the next page.

Field	Description
`value`	The field name in each entry that serves as a cursor.
`param`	The query parameter to use for the cursor in subsequent requests.
`removeParams`	Remove other URL parameters when paginating (optional).

You can optionally set maximumPage to cap the number of pages fetched during a sync.

Runtime Variables

For API endpoints that require dynamic parameters (e.g. current date, user-specific IDs), you can define variables that are resolved at fetch time. Each variable has:

Field	Description
`name`	The variable name used in the URL, headers, body, or query parameters.
`default`	A static value or a dynamic expression evaluated at runtime.
`primitive`	The data type (string, number, etc.).

Variables can be referenced in the URL, headers, body, and query parameters. This enables building dynamic URLs like https://api.example.com/products?since={{last_sync_date}}.

How It Works

Reelevant sends an HTTP request to the configured URL with the specified method, headers, and body.
If pagination is configured, subsequent pages are fetched automatically.
The response is parsed based on the detected format.
Fields are extracted and made available for mapping.
On subsequent syncs, the URL is re-fetched and the data is updated.

Make sure your URL returns data in a supported format. The platform auto-detects the format from the response content type and content.
